316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)

316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)
316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)
316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery) 316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)

Large Image :  316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)

Product Details:
Place of Origin: Henan, China
Brand Name: Guojiang
Certification: ASME, PED, GB, ISO
Model Number: SH 813×8
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $25-10000
Packaging Details: Wooden cases, wooden pallets, steel pallets, or customized according to customer requirements
Delivery Time: 10-30 days
Payment Terms: T/T,L/C
Supply Ability: 50,000 pieces per month
Contact Now Chat Now

316L Stainless Steel Spherical Cap Head - Custom 813×8 Size (Sample Available, Fast Delivery)

description
Diameter: 813mm Wall Thickness: 8mm
Roughness: RA 0.1-0.8μm Thickness: 1mm -300mm
Material: Aluminum, 304, 316, 321, 2205, Q235, A36, Q245R, Q345R, SA-516Gr.60/65/70, 16MnDR, S275JR Etc.. Customization: Customise Products According To The Drawings And The Requirements

Compared with elliptical dished heads, spherical dished heads offer superior pressure-bearing performance but involve higher manufacturing difficulty. As a result, elliptical structures are more commonly used in medium and low-pressure vessels. When the design pressure exceeds 10MPa, the use of spherical dished heads can reduce wall thickness, significantly lowering material costs. In storage-type vessels, their geometric characteristics can increase the effective volume by more than 15%.
Product Specifications
Item Key Data
Diameter 813mm
Wall Thickness 8mm
Material SA-240M 316L
Reduction Ratio Approximately 10%
Brand GuoJiang
Production & Processing Details
Item Key Data
Forming Methods
  • Hot Forming: Applicable to thick-walled materials/high-strength alloys; stress relief annealing required after forming
  • Cold Forming: Suitable for 8mm-thick 316L stainless steel; no thermal deformation, ensuring structural precision
Surface Treatment
  • Sand Blasting: Ra 1.6μm - 3.2μm (enhances coating adhesion)
  • Pickling: Forms a passive film (improves corrosion resistance, meets hygiene standards)
  • Oil Coating: Food-grade anti-rust oil optional
  • Descaling: Mechanical/chemical descaling (ensures a clean surface before welding)
  • Customisation: E.g., mirror polishing for highly clean fields
Inspection Standards
  • Ultrasonic Testing (UT): 100% coverage of key parts to detect internal cracks and inclusions
  • Radiographic Testing (RT): Complies with ASME BPVC Sec.V Level II standards
  • Penetrant Testing (PT): For non-ferrous materials, ensuring no surface leakage
  • Time of Flight Diffraction (TOFD): Accuracy ±0.1mm, precisely detects internal defects
Standards & Certifications
Item Key Data
Applicable Standards
  • International Standards: ASME BPVC Sec.VIII Div.1/2 (North America & global), PED 2014/68/EU (CE certification for European markets)
  • National Standards: GB/T 25198-2023 (China)
  • Regional Standards: Adaptable to JIS B8243, EN 13445
Certifications
  • ISO 9001:2015 Quality Management System Certification
  • ASME "U" Stamp
  • PED Module H Certification
Application Scenarios
Application Industry Applicable Equipment/Scenarios
Chemical Industry Small and medium-sized reactors, corrosive medium storage tanks (316L material resists acid and alkali erosion)
Food & Pharmaceutical Industry Food sauce storage tanks, pharmaceutical raw material reaction vessels (meet hygiene standards, avoid material contamination)
New Energy Field Hydrogen storage tanks, lithium battery material mixing equipment (lightweight design + corrosion resistance)
Water Treatment Industry Pressure chamber heads for reverse osmosis equipment (resists chloride ion corrosion, suitable for complex medium environments)
Packaging & Services
Item Key Data
Packaging Solutions
  • Wooden Cases: For precision heads, waterproof and shockproof, export-grade fumigation
  • Wooden Pallets: For bulk orders, stackable, load capacity ≥1000kg
  • Steel Pallets: For heavy heads (≥500kg), reusable, corrosion-resistant
  • Customised Packaging: E.g., vacuum packaging for stainless steel heads, seaworthy packaging for export shipping
Customisation & After-Sales Services
  • Customisation Services: Adjust size, material, forming process, etc., according to drawings
  • Technical Support: Free FEA pressure simulation, 2D/3D drawing design
  • Sample Service: Small-batch sample testing (5-10 units)
  • Delivery Cycle: 20 days for standard heads, 30 days for customised heads

Tag:

Stainless Steel Spherical Cap Head,

Stainless Steel Cap Head,

316L Spherical Cap Head
